Fits YCJH-IH Tractorused for
Pos.
|
Part No | Qty | Parts name | Comments |
YCJH-01 | 390011R91 | [1] | PLATE ASSY. | IH PLATE ASSY, dual clutch pressure Superseded by part number: 390011R92 |
YCJH-02 | 179821 | [6] | BOLT,Hex, 5/16" - 18 x 1 3/8", Gr 5 | IH Superseded by part number: 413-522 |
YCJH-03 | 103320 | [6] | LOCK WASHER,5/16" | IH WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583 |
YCJH-04 | 392502R1 | [3] | PIVOT PIN | IH PIN, pivot Superseded by part number: 3047750R1 |
YCJH-05 | 635495R1 | [3] | SCREW | IH adjusting Superseded by part number: 635495R2 |
YCJH-06 | 392499R1 | [3] | FINGER | IH LEVER, clutch Superseded by part number: 392499R2 |
YCJH-07 | 635494R1 | [3] | VALVE SPRING | IH SPRING, retracting |
YCJH-08 | 392503R1 | [3] | PIN | IH stud rod |
YCJH-09 | 635496R1 | [3] | BLOCK | IH ROD, stud |
YCJH-10 | 392504R1 | [3] | PIN | IH SPRING, hair pin |
YCJH-11 | 392497R1 | [1] | P PLATE, back | |
YCJH-12 | 392500R1 | [1] | SPRING | IH Belleville Superseded by part number: 635490R1 |
YCJH-13 | 635491R1 | [1] | PLATE | IH pressure |
YCJH-14 | 392492R91 | [1] | DISC | IH ASSY, PTO driven |
YCJH-15 | 392498R1 | [1] | PLATE | IH flywheel |
YCJH-16 | 392501R1 | [1] | SPRING | IH Belleville Superseded by part number: 635490R1 |
YCJH-17 | 392496R1 | [1] | PLATE | IH pressure |
YCJH-18 | 114493 | [6] | JAM NUT,Jam, 5/16"-24, G5 | IH Superseded by part number: 86637933 |
YCJH-19 | 355106R1 | [3] | P SCREW, cap | |
YCJH-20 | 392493R91 | [1] | PACKAGE | IH clutch facing, consists of two facings and eight rivets, 392495R1 Superseded by part number: 392492R91 |
YCJH-21 | 392495R1 | [8] | P RIVET, clutch facing | |
YCJH-22 | 399536R91 | [1] | DISC | IH ASSY, clutch drive, will work for 390010R91 Superseded by part number: 399536R92 |
